Ravatherm XPS X 700SL Extruded Thermal Insulation | 1250mm x 600mm

Ravatherm XPS X 700SL - 1250 x 600mm: Ultimate Insulation Solution

Ravatherm XPS X 700SL extruded polystyrene (XPS) thermal insulation is engineered for the most demanding applications, including very high load-bearing floors such as cold stores and aircraft hangars. Its superior properties stem from a closed-cell material structure, offering unmatched performance in a range of settings.

Product Specifications:

• Length: 1250mm
• Width: 600mm
• Coverage: 0.75m²
• Edge Profile: Ship Lap
• Thermal conductivity: 0.032 W/mK
• Compressive Strength (@ 10% deformation): 700 kPa
• Water vapour diffusion resistance factor: 100μ
• Fire Performance: Euroclass E

Exceptional Properties and Benefits:

• Permanently High Thermal Insulation: Provides consistent temperature control, crucial for energy efficiency and comfort in sensitive environments.
• Negligible Moisture Uptake: Its closed-cell structure ensures minimal water absorption, maintaining integrity and insulation performance.
• High Strength and Rigidity: Ready to withstand heavy loads, making it ideal for critical areas like cold storage and hangar floors.
• Dimensional Stability: Maintains its shape and effectiveness over time, even under thermal fluctuation.
• Resistance to Rot and Deterioration: Durable materials and construction offer long-lasting protection and low maintenance.
• Simple and Quick Installation: Designed for ease and efficiency, it minimizes installation time and waste.

Advanced Manufacturing for Superior Performance:

Ravatherm XPS X 700SL is produced through an advanced extrusion process, resulting in a homogeneous, closed-cell material structure. This method ensures a smooth surface skin (extrusion skin) and imparts numerous advantageous material properties:

• Water and Frost Resistance: Ensures long-term durability and protection against moisture and cold.
• High Compressive Strength: Capable of supporting substantial loads without deformation.
• High Flexible Rigidity: Offers flexibility under load, preventing cracks and structural damage.
• High Vapor Diffusion Resistance: Blocks moisture transmission, safeguarding the insulation layer and interior spaces.

Versatile Application for Comprehensive Protection:

Ravatherm XPS X 700SL can be efficiently applied above or below the reinforced concrete slab, or directly onto a compacted gravel bed. This versatility simplifies the construction process, potentially saving a layer of blind concrete and reducing costs.

Built-in Advantages for Modern Construction:

• Built-in Insulation-Protection: Enhances the durability and lifespan of construction projects.
• High Insulation Performance Over Decades: Ensures lasting efficiency with minimal upkeep.
• High Moisture Resistance and Low Compression: Keeps moisture out while maintaining structural integrity.
• Frost-Resisting with High E-Modulus: Remains effective even in freezing temperatures, resisting freeze-thaw cycles.

Ravatherm XPS X 700SL sets the standard for thermal insulation in heavy-duty applications, offering a blend of high performance, durability, and ease of use that modern projects demand.
